PLEXIGLAS® Optical hard coated 0A000 HC | Overview

PLEXIGLAS® Optical Hard Coated 0A000 HC is an extruded acrylic sheet known for its outstanding optical clarity and durability. Featuring a specialized hard coating, this material is designed to resist abrasion and chemical damage, making it ideal for demanding applications, where the material is subjected to heavy use and cleaning.
PLEXIGLAS® Optical hard coated 0A000 HC
SHOW

PLEXIGLAS® Optical hard coated 0A000 HC | Description

Key Features:
  • High Light Transmission: The sheet boasts a light transmission of up to 92%, ensuring excellent visibility and clarity​
  • Durability: With a hard-coated surface, PLEXIGLAS® Optical HC is highly resistant to scratches and chemicals, outperforming standard acrylic sheets​
  • Temperature Resistance: This material is capable of withstanding temperatures up to approximately 70°C (158°F), suitable for various environments​
  • UV Protection: The optical sheet is UV absorbent, which helps prevent yellowing and degradation over time, ensuring long-lasting performance​
Applications: PLEXIGLAS® Optical HC is well-suited for a range of uses, including:
  • Electronic displays
  • Industrial glazing
  • Signage
  • Furniture and wall paneling
  • Picture glazing and display cases​
Processing: The material can be processed similarly to standard PLEXIGLAS®, but care should be taken with edge finishing. Mechanical cleaning methods should be avoided to prevent scratches on the coated surface​

PLEXIGLAS® Optical hard coated 0A000 HC | Parameters

Characteristics Value Units Test Method
Series Plexiglass
Thickness 4 mm
Color Clear
Light Transmission 92 % ISO 13468-2
Tensile strength 67,5 MPa ISO 527
Impact strength 10 kJ/m²
Pencil hadrness 5 H DIN EN 13523-4
Type Extruded

PLEXIGLAS® Optical hard coated 0A000 HC | Warranty

Technical data

All information and statements contained in this document are based on the manufacturer's or material supplier's sources known to us at the time of filing. PERLON, spol. s r.o. believes them to be reliable in good faith, but the accuracy and/or completeness of such information is not guaranteed. The data should be considered representative or typical only and should not be used for specification purposes. Manufacturers reserve the right to make changes to the design, construction and technical data of products without prior notice.

Use of the product

Many factors beyond the control of PERLON, spol. s r.o. and known only to the user may affect the use and performance of materials in a particular application. Therefore, we recommend that the customer perform their own tests of the suitability and performance of the material for their application and to a responsible extent for reliable results. As a result, the customer is solely responsible for evaluating the product and determining if it is suitable for the customer's application, including evaluating workplace hazards and reviewing all applicable regulations and standards. Failure to properly evaluate, use, or comply with all applicable safety regulations may result in injury, illness, death, and/or property damage if the material and associated safety is not properly evaluated. PERLON, spol. s r.o. makes no warranties of fitness for a particular purpose.

Limitation of liability

PERLON, spol. s r.o.  shall not be liable for any loss or damage arising out of or relating to the product material, whether direct, indirect, special, incidental or consequential (including, but not limited to, loss of products or business), regardless of the applicable legal practice, including but not limited to warranty, contract, negligence or strict liability.
